When standard hydraulic cylinders can't meet the requirements of your application, custom hydraulic cylinders provide the performance, durability, and precision needed to keep equipment operating efficiently. From unique mounting configurations to specialized materials and integrated position feedback systems, custom cylinder solutions are designed around your exact specifications.

At Sheffer Corporation, we understand that no two applications are exactly alike. That's why we work closely with engineers, OEMs, distributors, and end users to design and manufacture custom hydraulic cylinders that solve complex challenges while delivering long-term reliability.

What Are Custom Hydraulic Cylinders?

Custom hydraulic cylinders are cylinders specifically engineered to meet application requirements that cannot be addressed by standard, off-the-shelf products. These cylinders are designed with unique dimensions, mounting styles, bore sizes, stroke lengths, pressure ratings, coatings, seals, and accessories to optimize performance in a specific environment. While Sheffer is a household name when it comes to NFPA Tie-Rod Cylinders, custom design and application is the primary product offering of our 75,000 sq ft Cincinnati facility.

Custom designs are commonly used when equipment requires:

• Non-standard bore or stroke dimensions
• Special mounting configurations
• Corrosion-resistant materials
• Extreme temperature capabilities
• Position sensing technology
• High-cycle operation
• Increased load capacity
• Specialized paint or coating systems
• Unique port locations or piping arrangements

By tailoring the cylinder to the application, manufacturers can improve efficiency, reduce downtime, and extend service life.

Why Choose Custom Hydraulic Cylinders?

Many hydraulic systems operate under conditions that standard products were never intended to handle. Investing in custom hydraulic cylinders can provide several advantages:

• Improved Equipment Performance

  • A cylinder designed specifically for your machine ensures optimal force output, speed, and operational efficiency. Rather than modifying your equipment to fit a standard cylinder, a custom solution is built to fit your design.

• Increased Reliability

  • Custom cylinders can incorporate upgraded materials, seals, coatings, and rod finishes that withstand harsh operating environments. This results in longer service intervals and reduced maintenance costs.

• Enhanced Safety

  • Applications involving heavy loads, high pressures, or critical positioning often require engineered solutions. Custom hydraulic cylinders can be designed with safety factors and performance features tailored to the application.

• Reduced Downtime

  • When a cylinder is engineered correctly from the start, equipment operates more consistently, reducing unexpected failures and costly production interruptions.

Key Design Considerations for Custom Hydraulic Cylinders

When developing a custom hydraulic cylinder, engineers evaluate several critical factors:

Bore and Stroke Requirements

Cylinder bore size determines force output, while stroke length defines travel distance. Proper sizing ensures efficient system performance.

Mounting Style

Mounting selection significantly impacts cylinder performance and service life. Common options include:

• • • Clevis mounts
    • Trunnion mounts
    • Flange mounts
    • Foot mounts
    • Spherical bearing mounts

Selecting the proper mounting style helps minimize side loading and extends cylinder life.

Rod Material and Finish

Custom hydraulic cylinders can utilize specialized rod materials such as chrome-plated steel or stainless steel to improve corrosion resistance and durability.

Seal Selection

The operating environment determines the appropriate seal package. Factors include:

• • • Temperature
    • Pressure
    • Fluid compatibility
    • Contamination exposure
    • Cycle frequency

Position Feedback Integration

Many modern systems require real-time cylinder position data. Integrated technologies may include:

• • • Magnet transducers
    • Linear encoders
    • Proximity switches
    • Reed switches

These features allow operators to monitor and control cylinder movement with exceptional precision.

Sheffer's Custom Hydraulic Cylinder Capabilities

For decades, Sheffer has been helping customers solve complex hydraulic challenges with engineered cylinder solutions.

Our team designs and manufactures custom hydraulic cylinders featuring:

• NFPA hydraulic cylinders
• Large bore hydraulic cylinders
• Heavy-duty industrial cylinders
• Position feedback systems
• Specialized coatings and paint systems
• Stainless steel components
• Custom mounting configurations
• Application-specific porting arrangements
• High-pressure cylinder designs

Whether you need a single prototype or a production run, our engineering team works directly with customers to ensure every cylinder meets performance expectations.

Partner with Sheffer for Custom Hydraulic Cylinders

Choosing the right hydraulic cylinder partner can make all the difference in equipment performance and reliability. At Sheffer, we combine decades of engineering expertise with a commitment to quality, responsiveness, and customer support.

If your application requires something beyond a standard catalog product, our team can help develop a solution built specifically for your needs.

Explore our custom cylinder capabilities at Sheffer Custom Cylinders or request a quote through our Express Quote form.

If you'd like to discuss your custom hydraulic cylinder project further with an engineer, follow our link below and we'll reach out to you right away!
